Paper Machine - Kraft

Capacity: 100 TPD Kraft
Machine Speed: 275 MPM
Wire Width: 2.92 M
Wire Length: 30.40 M
Trimmed Width: 106”
Head Box: Open Type

Press: 3 Nos., Bi- Nip with 3rd Press

1st Press:  Top Roll: Suction (700mm Dia), Centre Roll: Granite (1000mm Dia), Face Length: 108.66”
2nd Press: Plain Bottom Roll: Rubber (700mm Dia), Face Length: 108.66”
3rd Press:  Top Roll: Micro Rock (700mm Dia), Bottom Roll: Rubber (700mm Dia), Face Length: 108.66”

Dryer Section: 26 Nos. 1350mm Diameter, Face Length : 108”

1 Nos. Yankee Cylinder 10’
Hi-Velocity Hood

Line Shaft Drive

Calender: Top/Bottom 4 Chilled Rolls. Roll Dia: 400mm each

Pope Reel: 1 M Diameter Drum, Automatic/Pneumatic Loading

Pulp Mill :

4 Nos. Washer Drums 2M X 2M

Celleco Centri Cleaners

Conical Refiner

Tri Disc Refiner

Pulper

Pressure Screen

Decker Thickener

3M Screen

Vibrating Screen

Agitators, Motors & Pumps
